WEBINAR: Springback and Warpage Compensation
LIVE WEBINAR
Join us to discover how to address a challenging aspect in the manufacturing process, ‘springback and warpage compensation‘. By not taking a proactive approach to resolve springback/warp ahead of stamping or injecting molding causes considerable rework later when product changes need to be made as there is no direct correlation between the CAD model and the final product.
Achieve Right Part Tooling the First Time by using 3DEXPERIENCE® CATIA modeling software, you can automatically create a tooling model that compensates for part warping or springback in the manufacturing process. It minimizes or eliminates manual finishing, reduces tooling costs by 50%, and cuts CAD model rework by 80%.
Whether you start with an analysis prediction of warp or springback or a scan of a deformed part, you can generate a compensated tooling model in just one click.
When using a scanned part as input, the process still involves just three additional pre-processing steps. After importing the scan data, 3DEXPERIENCE CATIA users can quickly filter and repair imperfections or isolate areas for deformation compensation. The Reverse Shape Optimization toolset measures the distance between the scan and design data, generating an optimized vector field. From there, it’s just a simple click to create the compensated tooling model.
Tooling Model Compensation – From Analysis Predictions
Mold flow and sheet metal forming analysis tools can provide a ‘displacement vector field’ that directly compensates the CAD model in 3DEXPERIENCE. Starting with the displacement data (X, Y, Z, dX, dY, dZ), you can morph the CAD model in one click, adjusting parameters such as deformation scale or even reversing the deformation to create the compensated tooling model.
Whether you start with an analysis prediction of warp or springback or a scan of a deformed part,
you can generate a compensated tooling model in just one click.
Join Jason Curtis , Director of Applications Engineering at GoEngineer, to learn how, by automating this process, manufacturers can drastically reduce time and effort spent on tooling adjustments and ensure more accurate, efficient production.
Springback and Warpage Compensation
LIVE Webinar Agenda
February 13th, 2025 | 12 PM PST/3 PM EST
| Duration (minutes) | Start (minutes) | Topics |
| 1 | 0.00 | Welcome and Introduction |
| 30 | 1.00 | Solution overview and live demonstrations |
| 14 | 31.00 | Summary, takeaways, and Q&A |
